2022 Linear Hot Melt Adhesive Labelling Machine

Overview

Linear Hot Melt Adhesive Labelling Machine designed for the application of OPP, BOPP and paper wrap-around labels on PET, glass and aluminium containers.

Manufactured in 2022, this machine has completed approximately 500 operating hours, making it an excellent opportunity to acquire a near-new labelling solution at a significant saving over new equipment.

Located in Cape Town, South Africa, the machine is suitable for beverage, food and industrial packaging applications.

Production Capability

Nominal output:

Up to 12,000 bottles per hour (500ml)

Suitable container materials:

• PET
• Glass
• Aluminium

Bottle diameter range:

45 mm – 105 mm

Supported bottle sizes:

• 2L
• 3L
• 1L (optional change parts)

Key Machine Features

Linear hot melt adhesive labelling system

Suitable for OPP, BOPP and paper labels

Designed for multiple bottle materials

Schneider PLC and servo control system

Touchscreen operator interface

Precision servo-driven label application

Low operating hours

Quick format change capability

Technical Summary

Model: LT-200

Machine Type: Linear Hot Melt Adhesive Labeller

Manufactured: March 2022

Operating Hours: Approx. 500 hours

Output: Up to 12,000 BPH (500ml)

Power Supply: 380V, 3 Phase, 50Hz

Installed Power: 8 kW

Main Drive Motor: 1.5 kW

Dimensions: 2,520 × 1,860 × 1,950 mm

Weight: 2,500 kg

Operating Air Pressure: 0.5 MPa

Label Types: OPP, BOPP, Paper

Label Length: 125–320 mm

Label Height: 40–140 mm

Bottle Diameter: 45–105 mm

Control & Electrical Components

PLC – Schneider (France)

Touchscreen HMI – Schneider (France)

Servo Drive – Schneider (France)

Sensors – Panasonic / SICK (Japan / Germany)

Encoder – Omron (Japan)

Photoelectric Sensors – Autonics (South Korea)

Low Voltage Electrical Components – Schneider (France)

Condition

Manufactured in 2022 and operated for approximately 500 hours only.

Supplied with change parts for:

• 2L bottles
• 3L bottles

Optional change parts available for 1L bottles.

Availability & Project Support

Full support available including:

• Technical due diligence
• Dismantling and loading
• Export packing and logistics
• Delivery coordination
• Installation and commissioning support if required

Additional technical documentation and photographs are available on request.

Site inspections can be arranged for qualified buyers.
