Technical Summary

Capacity: 95,000 Litres (95m³)

Availability: 3 units

Orientation: Vertical

Material: AISI 304 Stainless Steel

Condition: Second-hand / Never Used

Diameter: Ø 3,300 mm

Total Height: 11,647 mm

Design Density: Up to 1,100 kg/m³

Pressure: Atmospheric

Construction: Single-skin

Top Type: Conical

Bottom Type: Sloping bottom

Support: Stainless steel skirt, designed to be filled with concrete

Specification

Vertical cylindrical storage tank design

Manufactured from AISI 304 stainless steel on all product-contact surfaces

95,000-litre nominal capacity

Suitable for food industry applications

Atmospheric pressure design

Single-skin construction with no insulation or heat exchanger

Conical top design

Sloping bottom configuration

Stainless steel support skirt designed for concrete filling

1 x AISI 304 stainless steel manway

No agitator currently fitted; agitator available as an optional addition

No agitator flange currently fitted

Designed for fixed installation

Available immediately.

Full support available including:
